Cisco UCCX Finesse Mobile Agent Configuration Guide

September 20, 2018
Cisco UCCX Finesse Mobile Agent Configuration Guide

Cisco Finesse Mobile Agent App Benefits

Contact Center Agent and Supervisor without Desktop PC Dependency

Comstice Mobile Agent App is a Cisco Finesse client on IPhone, IPad and Android devices. It helps agents to switch between desktop and mobile with the same agentID. Users can login as an agent and receive customer calls through their mobile phone.

Built-in Cisco Finesse Softphone using WebRTC

Comstice Mobile Agent app also includes a WebRTC softphone. Calls are retrieved through Comstice WebRTC Gateway on site and sent to Mobile Agent app as a WebRTC call. No VPN or a specialist firewall required. Agents can make and receive calls using Comstice Mobile Agent app without any Cisco Jabber needed.

Softphone or Mobile Phone Line

Comstice Mobile Agent app can also be used with mobile phone line. Calls are delivered through mobile phone line with guaranteed audio quality, particularly when the mobile agents are on the move.

Access to Customer CRM Data

Using the built-in mobile browser, agent can access to the CRM or ticket details of the calling customer and update the customer data. Comstice Mobile Agent App can integrate with any web-based CRM platform such as SalesForce, ZenDesk and update customer details at the ticketing system.

Agent Selection based on Geolocation

Geolocations of mobile agent app users can be monitored centrally using Comstice Location Server hosted in your network. Once calling party's geolocation is identified either using speech recognition or a front desk agent, the call can be routed automatically by Cisco UCCX to the nearest agent available.

Comstice Mobile Agent with Cisco UCCX Finesse

Cisco UCCX uses Cisco CUCM Extend and Connect feature to help Finesse agents to login without any Cisco phone or softphone. Comstice Mobile Agent app for Cisco Finesse utilises Extend and Connect feature to deliver customer calls to agent mobile phones.

Requirements

  • Cisco UCCX v10 or higher, Cisco CUCM v9.0 or higher
  • Cisco IM and Presence Server v9.0 or higher

Configuring Cisco UCCX

Cisco UCCX utilises Cisco CUCM Extend and Connect feature to allow agents to use non-Cisco device to receive customer calls. By default, Cisco Extend and Connect feature creates a permanent call to the third party phone as soon as agent logs as Cisco Finesse agent. This is obviously not acceptable in mobile phones, therefore we need to disable "Persistent Connection" feature in Cisco UCCX.

Go to Cisco UCCX Admin page > System > System Parameters > Persistent Connection and select "Disable"

Cisco UCCX Finesse Mobile Agent Configuration

Configuring Extend and Connect

Here are the main steps for configuring Cisco CUCM and CUPS for Comstice Mobile Agent in Cisco UCCX. The detailed steps can be found here;

  1. Please make sure that Cisco IM and Presence Server pre-installation tasks are complete.
  2. Add Cisco IM and Presence Server into Cisco CUCM Cluster;
    System > Server > Server Type > IM and Presence
    Mobile Agent UCCX Configuration Find and List Servers
  3. Install Cisco IM and Presence Server as a Cisco CUCM Subscriber
  4. Activate and start the IM and Presence services in Cisco Unified Serviceability
  5. Create Presence Redundancy Group in Cisco CUCM; System > Presence Redundancy Groups> Add New Mobile Agent UCCX Configuration Find and List UC Services
  6. Create UC Services for CTI and IM and Presence in Cisco CUCM; User Management > User Settings > UC Service
  7. Add UC Service for CTI
  8. Add another UC Service for IM and Presence in Cisco CUCM. Try to use the same naming convention given above.
  9. Create a new Service Profile in Cisco CUCM and select CTI and IM and Presence UC Services you created;
    User Management > User Settings > Service Profile
    Mobile Agent Service Profile
  10. Create an end user in Cisco CUCM for the agent or modify the existing end user for the agent.
  11. In the Service Settings section, select Enable User for Unified CM IM and Presence (Configure IM and Presence in the associated UC Service Profile) and then in UC Service Profile, select the profile that you created.
    In the Mobile Information section, select Enable Mobility.
    In Permissions, add Standard CCM End user and Standard CTI enabled.
    Navigate to User Management > Assign Presence End Users. Click the Agent User ID that you want to set up and then choose Assign Selected Users.
  12. Make sure that Cisco CUCM trunks and Route patterns are set up to call agent mobile phone numbers in Cisco CUCM.
  13. Create a Presence Gateway in Cisco IM and Presence Server
    Mobile Agent Presence Gateway
  14. Cisco CUCM simulates the user's device with CTI Remote Device feature. Create a new CTI Remote Device for the agent;
    Device > Phone > Add New > CTI Remote Device
  15. Complete the relevant settings in the Device Level such as CSS etc.Please make sure that you select the correct Rerouting Calling Search Space on the device level (down at the bottom, before Remote Destination settings). Otherwise, CTI Remote Device will not be able call out your third party phone.
  16. Add remote destination to the device. Please make sure that any outside prefixes are included to dial the agent mobile phone number.
  17. On the remote destination settings, you can name the remote destination as mobile
    Mobile Agent Remote Destination Information
    Also select "Enable Extend and Connect".
    Go back to the device level in the CTI Remote Device and select;
    Mobile Agent Associate Remote Destinations
  18. Configure Line 1 in CTI Remote Device;
    • Add an extension and calling permissions
    • Select "No Voicemail" explicitly on the voicemail settings
    • Set "No Answer Ring Duration" to 25 or higher
    • Set Maximum Concurrent: 2 Busy Trigger: 1
    • Associate the Line to the CUCM End User you created for the Finesse agent. (at the bottom of the page)
  19. (Optional) Configure Cisco UCCX Scripts Select Resource Step;
    • Click Connect Yes and set the Ring Time as 20 seconds.
    • This helps to avoid calls to be taken back to the queue by Cisco UCCX if call establishment gets delayed.


  20. (Optional) Create a CUCM Application User for accessing Corporate Directory: Comstice Mobile Agent app can access Cisco CUCM Corporate Directory, find and dial contacts. In order to do that, you need to create an application user in Cisco CUCM and let Comstice know about its details.
  21. Application user also needs to have AXL API Access. You can create a new role User Management > User Settings > Role and add AXL API Access
  22. Then User Management > User Settings > Access Control Group and assign the role from the top right dropdown "Assign Roles to Access Control Group"
  23. This will help Comstice Mobile Agent app to access CUCM Corporate Directory and Active Directory contacts if they are both integrated.
